Steba BS 1800 Touch - Filter; Towels; Command Description and Functioning

20
16
- Insert the 2 upper screws, contained in the same bag, taking care to leave a distance of 8 mm between the
head of the screws and the wall;
- Gripping the heater rmly, hook it onto the two screws; CAUTION! Before releasing the heater make sure
it is attached to the 2 screws.
- Then secure the product with the lower screw.
3. Filter
• This product is tted with a lter to protect the heating element from dust and dirt.
• The lter is removable to be easily cleaned with water (picture 5).
• To keep the heater in perfect condition, clean the lter once every six months REMEMBERING TO PUT IT BACK
AGAIN AFTERWARDS.
4. toWels
• The product is equipped with a towel rail and n. 4 additional hooks placed on rail's back side.
• Please do not push or embed towel close to the air outlet grid (picture 6) but place them as shown in picture 7.
5. coMManD DescriPtion anD Functioning
• The heater is tted with a double pole electromechanical ON/OFF switch on its left side. Switching off the product
the supply voltage is disconnected from all the internal components.
• The following controls are available on the front panel (picture 8):
A - Presence Sensor
B - Display
C - Show and increase
D - Show and decrease
E - Settings
F - Frost free mode
G - Programmed mode
H - Stand-by
I - Frost free mode led indicator
J - Programmed mode led indicator
K - Functioning led indicator
This bathroom fan heater features a presence sensor and an automatic power management function.
The presence sensor allows a reduced energy consumption, lowering automatically the ambient temperature when no
one is detected in the room, while it comes back to the set comfort temperature, maintaining it throughout the time of
someone's detection.
The automatic electronic power selection, instead, manages the consumption through an accurate and comfortable
regulation in order to automatically keep constant the selected temperature, according to what has previously been set
on the electronic thermostat.
The operation of the presence sensor cannot be disabled and the product can be used in two distinct modes: auto-
matic or programmed.
Automatic Mode
The product is set to work at a comfort temperature whenever someone is detected in the room. Should no one be
detected in the room for at least 10 minutes, the heater will automatically set the Eco mode (3,5°C less than the set
Comfort temperature). Should no one be detected in the room for more than 36 hours, the heater will automatically set
the Frost free mode (7°C). In case someone should be detected again for at least 2 minutes, the product will automa-
tically increase the temperature to the comfort level.
In automatic mode is also available a special feature, which is activated at user’s choice, which allows to detect the
possible opening of a window and force the functioning to the Frost free mode to minimize energy waste.
Programmed Mode
The product can be programmed, on hour base, for each day of the week. For each hour of the day it is possible to
dene the reference temperature to be reached/maintained, choosing between Comfort, Eco or Frost free.
In programmed mode the presence detector and the open window detection functions are disabled so that the
product can correctly follow the temperature prole dened by the user.
16
- Insert the 2 upper screws, contained in the same bag, taking care to leave a distance of 8 mm between the
head of the screws and the wall;
- Gripping the heater rmly, hook it onto the two screws; CAUTION! Before releasing the heater make sure
it is attached to the 2 screws.
- Then secure the product with the lower screw.
3. Filter
• This product is tted with a lter to protect the heating element from dust and dirt.
• The lter is removable to be easily cleaned with water (picture 5).
• To keep the heater in perfect condition, clean the lter once every six months REMEMBERING TO PUT IT BACK
AGAIN AFTERWARDS.
4. t
oWels
• The product is equipped with a towel rail and n. 4 additional hooks placed on rail's back side.
• Please do not push or embed towel close to the air outlet grid (picture 6) but place them as shown in picture 7.
5. coMManD DescriPtion anD Functioning
• The heater is tted with a double pole electromechanical ON/OFF switch on its left side. Switching off the product
the supply voltage is disconnected from all the internal components.
• The following controls are available on the front panel (picture 8):
A - Presence Sensor
B - Display
C - Show and increase
D - Show and decrease
E - Settings
F - Frost free mode
G - Programmed mode
H - Stand-by
I - Frost free mode led indicator
J - Programmed mode led indicator
K - Functioning led indicator
This bathroom fan heater features a presence sensor and an automatic power management function.
The presence sensor allows a reduced energy consumption, lowering automatically the ambient temperature when no
one is detected in the room, while it comes back to the set comfort temperature, maintaining it throughout the time of
someone's detection.
The automatic electronic power selection, instead, manages the consumption through an accurate and comfortable
regulation in order to automatically keep constant the selected temperature, according to what has previously been set
on the electronic thermostat.
The operation of the presence sensor cannot be disabled and the product can be used in two distinct modes: auto-
matic or programmed.
Automatic Mode
The product is set to work at a comfort temperature whenever someone is detected in the room. Should no one be
detected in the room for at least 10 minutes, the heater will automatically set the Eco mode (3,5°C less than the set
Comfort temperature). Should no one be detected in the room for more than 36 hours, the heater will automatically set
the Frost free mode (7°C). In case someone should be detected again for at least 2 minutes, the product will automa-
tically increase the temperature to the comfort level.
In automatic mode is also available a special feature, which is activated at user’s choice, which allows to detect the
possible opening of a window and force the functioning to the Frost free mode to minimize energy waste.
Programmed Mode
The product can be programmed, on hour base, for each day of the week. For each hour of the day it is possible to
dene the reference temperature to be reached/maintained, choosing between Comfort, Eco or Frost free.
In programmed mode the presence detector and the open window detection functions are disabled so that the
product can correctly follow the temperature prole dened by the user.
IT - 3. Filtro
• Ogni120oredifunzionamentol'utentevieneavvisatodellanecessitàdipulireilltropostosulretrodelprodotto.
L'avvisoavvienetramitelavisualizzazioneadisplaydellascrittascorrevole
" PULIrE FILtro - CLEAn FILtEr - nEttoYEr FILtrE "
.
• Ancheseildisplayvisualizzalascrittasopraindicatailprodottocontinuaafunzionarenellamodalitàattivaal
momentodellacomparsadell'avviso.
• Lapressionediunqualsiasitastocancellalascrittadaldisplay.Essatorneràadesserevisibiledopoun'ulteriore
oradifunzionamentodeltermoventilatore.
• Lapressioneprolungatadeltastomode
conavvisoattivoinveceazzerailcontatoreinternoel'avvisotorne-
ràadesseremostratodopoulteriori120oredifunzionamento.Laconfermadell'avvenutoazzeramentoèdata
dallavisualizzazionesuldisplayper5"dellascritta
"donE "
.
EN - 3. Filter
• Every120workinghours,theuserisnotiedoftheneedtocleanthelteronthebackoftheproduct.Thewarning
isgivenintheformofarunningmessageonthedisplaythatreads:
" PULIrE FILtro - CLEAn FILtEr - nEttoYEr FILtrE "
.
• Evenwhenthedisplayisshowingthemessageindicatedabove,theproductcontinuestoworkinthemodeactive
atthetimethenoticationappears.
• Ifanykeyispushedthetextisremovedfromthedisplay.Itwillonceagainbedisplayedwhenthefanheaterhas
beenrunningforanotherhour.
• Byholdingthemodekeydownwhenthenoticationisdisplayed,thebuilt-incounterisresetandthenotication
willbedisplayedagainafteranother120workinghours.Conrmationofresettingisgivenbyamessageonthe
displayfor5secondsthatreads
"donE "
.
DE - 3. Filter
• Alle120BetriebsstundenwirdderBenutzeraufdieNotwendigkeitderReinigungdesFiltersaufderHinterseite
desGerätesaufmerksamgemacht.DerHinweiserfolgtübereineAnzeigeaufdemDisplaymitderLaufschrift:
" PULIrE FILtro - CLEAn FILtEr - nEttoYEr FILtrE "
.
• Auch wenn die oben gezeigteAufschrift auf demDisplay angezeigt wird, funktioniert dasGerät weiterhin im
Modus,derbeimErscheinendesHinweisesaktivwar.
• DurchDrückenirgendeinerTastewirddieAufschriftaufdemDisplaygelöscht.Sieerscheintnacheinerweiteren
BetriebsstundedesHeizlüfterserneut.
• DurchlangesDrückenderTaste„Mode“beiaktivemHinweissetztdeninternenZähleraufNullundderHinweis
wirderstnachweiteren120Betriebsstundenwiederangezeigt.DieBestätigungdererfolgtenNullsetzungerfolgt
durchdieAnzeigederAufschrift
"donE "
für5"aufdemDisplay.
