Assembly:
Before every assembly or disassembly the device must be turned off!
Bulge
Space
Lower stand
tube
Base
Screw and
plane washer
Turning in
a clockwise
direction
Upper
stand
tube
Thread
Fig. 1 Fig. 2
Assembly of the base and the stand
1. Insert the lower stand into the hole at the base. Tighten the stand with the 4
screws on the base (Fi. 1).
2. Afterwards, insert the upper stand to the lower one and clockwise screw tightly
(Fig. 2).
