13
Fan blade
lock
Shaft
pin
Safety guard
Securing
clip
Motor
shaft
Motor
cover
Guard
nut
Fan blade
Fig. 3
Assembly of the fan blades
and the safety guard
1. Remove the fan blade lock and the guard nut from the moto shaft. Place the rear
safety guard onto the shaft pin. Tighten the safety guard with the guard nut at
the motor (Fig. 3).
