Page 7 of 10
939504633 Rev Y
Multipurpose Power In Feed - Strain Relief
Installation
Install a strain relief bracket to one of the following
locations: The underside of a utility tray, the top or
bottom of a beam, or the inside face of a junction
post.
1. Drill a pilot hole for the strain relief bracket
mounting screw. Secure the bracket and the conduit
into the bracket with the provided hardware.
1a
1b
1c
To Next Page
