HOW TO USE
3. Using the location identifier note pad, record information on note pad of the location and
corresponding channel for each mircrophone/clamp. This will allow you to properly assign
the problem noise to the proper malfunctioning part while conducting the road test.
4. It is highly recommended that if earphones are used during diagnosis (there is an
earphone jack available on the receiver), that there be a separate driver for the vehicle.
CAUTION: It is illegal in many jurisdictions to operate a motor vehicle while
wearing earphones.
5. Before conducting the road test, turn on the on/off-volume control switch located on
the front of the STEELMAN
®
Wireless ChassisEAR
®
receiver. Select the first channel and
adjust the volume to the desired level. Various volume levels may reveal different sounds
and problems. Initially make a mental note of the sounds you hear as you listen. Next,
push each channel according to the location and make notes accordingly. You may make
instant cross comparisons of two locations, for example, channels #2 and #4, just by
pushing the channel indicators in an alternating manner.
IMPORTANT: Make notes while driving (being cautious) as to what is heard on each channel
(rattles, squeaks, grinding, whining, etc.). When you have returned to the shop, you can then
zero in on the exact location of the noise/problem.
FUEL INJECTORS: It is quick and easy to hook up the STEELMAN
®
Wireless ChassisEAR
®
clamps on the fuel injectors. The “tapping” solenoids are easily heard. If a clear metal-to-metal
“ringing” sound is heard, then the injector is clean. If the “needle” inside the solenoid is making
a dull “thud”, then a deposit buildup more than likely exists inside the injector. A cleaning of
the injectors is suggested. It is important to listen to the injectors before and after cleaning in
case one is still dirty after cleaning.
REPLACEMENT PARTS
PART # DESCRIPTION
61082 Wireless ChassisEAR
®
Kit
61082-00 Wireless ChassisEAR
®
Unit
61082-01 WCE Transmitter - Channel #1
61082-02 WCE Transmitter - Channel #2
61082-03 WCE Transmitter - Channel #3
61082-04 WCE Transmitter - Channel #4
61082-05 *WCE Transmitter - Channel #5
61082-06 *WCE Transmitter - Channel #6
PART # DESCRIPTION
61082-07
Cable Leads / Clamps
- All Channels
61082-08 Earphones
61082-09 Blow Molded Case
61082-10 User Manual / Warranty Card
61082-11
Location Identier Note Pad
(25 sheets per pad)
61082-12 Velcro Straps (12 ea.)
61082-13 Nylon Straps (12 ea.)
(*) Optional - not shipped with initial kit
