ATTACHING TO A BOOM ARM
1 Secure the included Boom Arm Adapter (13) onto a Microphone
Boom Arm. The Boom Arm Adapter (13) supports 3/8” and 5/8”
thread sizes.
2 Remove the Thumb Screw (8) and Microphone Stand (11) from the
Microphone.
13
8 11
3 Align the Boom Arm Adapter (13) with the Shock Mount Adapter
Holes (7.1) and secure the Boom Arm Adapter (13) with the Thumb
Screw (8). Make sure the Thumb Screw Insert Groove (8.1) lines up
with the Boom Arm Adapter Hole Notch (13.1). Rotate the Thumb
Screw as needed to insert into the Boom Arm Adapter Hole.
4 Position your boom arm for use.
Note: Alias can be rotated without aecting performance.
8.1
7.1
13.1
13
8
