Steffes 2102 - Parts List

PARTS LIST
2100 Series Appendix A.03
* Manual and auto reset limits are not interchangeable. Verify serial number and/or style of limit switch before ordering.
**Optional voltages or wattages are available. Contact factory with model number and serial number of the heater.
Ref
No.
Description
2102
Plug-in
Item #
2102
Item #
2103
Item #
2104
Item #
2105
Item #
2106
Item #
1.
Processor Control Board
1023065R
1023065R
1023065R
1023065R
1023065R
1023065R
2.
Processor Control Board Mounting Bracket
5943412
5943412
5943412
5943412
5943412
5943412
3.
Faceplate Label
1159029
1159029
1159029
1159029
1159029
1159029
4.
Outdoor Temperature Sensor (optional)
1302033
1302033
1302033
1302033
1302033
1302033
5.
Wiring Harness, Low Voltage
1011647
1011647
1011647
1011647
1011647
1011647
6.
Base I/O Relay Board
1023078R
1023078R
1023078R
1023078R
1023078R
1023078R
7.
Line Voltage Base I/O Barrier
1159060
1159060
1159060
1159060
1159060
1159060
8.
Interface Cable, 18”
1010014R
1010014R
1010014R
1010014R
1010014R
1010014R
9.
*Discharge Air High Limit Switch (285 Degree) Auto
1012018R
1012018R
1012018R
1012018R
1012018R
1012018R
ʺ
*Discharge Air High Limit Switch (285 Degree) Manual
1012080R
1012080R
1012080R
1012080R
1012080R
1012080R
10.
Output Sensor (Thermocouple)
1040822
1040822
1040826
1040832
1040826
1040832
11.
**Blower Resistor
1017011
1017050
1017050
1017050
1017050
1017050
12.
**Blower Assembly
1021030R
1021032R
1021032R
1021032R
1021032R
1021032R
13.
Damper Actuator Assembly
1043107R
1043106R
1043106R
1043106R
1043106R
1043106R
14.
Damper Assembly
N/A
N/A
N/A
N/A
N/A
N/A
15.
Damper Assembly Insulation
N/A
N/A
N/A
N/A
N/A
N/A
16.
*Core Charging & Clearance Violation Limit Switches Auto
1040816R
1040816R
1040816R
1040817R
1040817R
1040818R
ʺ
*Core Charging & Clearance Violation Limit Switches Manual
1012082R
1012082R
1012082R
1012084R
1012084R
1012086R
17.
High Limit Switch Guide Tubes (cut to size)
1105003
1105003
1105003
1105003
1105003
1105003
18.
Core Charging High Limit Bracket
5940190
5940190
5940190
5940190
5940190
5940190
19.
Brick Core Sensor (Thermocouple)
1043102R
1043102R
1043103R
1043103R
1043104R
1043104R
20.
Brick Core Sensor Tube
5943222
5943222
5943220
5943220
5943220
5943220
21.
Room Temperature Sensing Side Panel
1040860
1040860
1040860
1040860
1040860
1040860
22.
Room Temperature Sensor
1013034
1013034
1013034
1013034
1013034
1013034
23.
Terminal Block, Room Temperature Sensor 2-position
1016018
1016018
1016018
1016018
1016018
1016018
24.
**Heating Elements
Contact factory with serial number of heater.
25.
High Temperature Vinyl
1015028
1015028
1015028
1015028
1015028
1015028
26.
Heat Storage Brick
5903010
5903010
5903010
5903010
5903010
5903010
27.
Painted Panel, Front
5943470
5943470
5943472
5943474
5943476
5943478
28.
Painted Panel, Top
5943050
5943050
5943052
5943054
5943056
5943058
29.
Painted Panel, Bottom
5943060
5943060
5943062
5943064
5943066
5943068
30.
Painted Panel, Right
5943420
5943420
5943420
5943420
5943420
5943420
31.
Painted Panel, Left
5943416
5943416
5943416
5943416
5943416
5943416
32.
Galvanized Panel, Front
5943010
5943010
5943012
5943014
5943016
5943018
33.
Galvanized Panel, Back
5943440
5943440
5943442
5943444
5943446
5943448
34.
Galvanized Plate, Bottom
5943430
5943430
5943432
5943434
5943436
5943438
35.
Galvanized Panel, Right
5943424
5943424
5943424
5943424
5943424
5943424
36.
Galvanized Base Tray
5943450
5943450
5943452
5943454
5943456
5943458
37.
Base Cap for Insulation
5943130
5943130
5943130
5943130
5943130
5943130
38.
Low Voltage Raceway Cover
5943216
5943216
5943216
5943216
5943216
5943216
39.
Insulation Panel, Front
1053010
1053010
1053012
1053014
1053016
1053018
40.
Insulation Panel, Back
1053010
1053010
1053012
1053014
1053016
1053018
41.
Insulation Panel, Bottom
1053020
1053020
1053022
1053024
1053026
1053028
42.
1 ½” Blanket Insulation, Outer
1050005
1050005
1050005
1050005
1050005
1050005
43.
1 ½” Blanket Insulation, Inner
1050004
1050004
1050004
1050004
1050004
1050004
44.
1" Blanket Insulation, Base
1050066
1050066
1050067
1050068
1050069
1050070
45.
Grill End Bracket, Right
5943426 (includes one right and one left grill end bracket)
46.
Grill End Bracket, Left
47.
Grill Support Rail
5943024
5943024
5943024
5943024
5943024
5943024
48.
Grill Slats
5943480
5943480
5943482
5943484
5943486
5943488
49.
Aluminized Air Channel, Top Back
5949060
5949060
5949062
5949064
5949066
5949068
50.
Aluminized Air Channel, Right
5943464
5943464
5943464
5943464
5943464
5943464
51.
Aluminized Air Channel, Left
5949028
5949028
5949028
5949028
5949028
5949028
52.
Mounting Hardware Package
1190038
1190032
1190032
1190032
1190032
1190032
53.
Wall Support Bracket
N/A
5943490
5943492
5943494
5943496
5943498
54.
Security Base Shell
5942114
N/A
N/A
N/A
N/A
N/A
55.
Security Base Filler
1190023
N/A
N/A
N/A
N/A
N/A
56.
Wiring Harness (umbilical cord) Conduit
N/A
1040800
1040800
1040800
1040800
1040800
57.
Cord Assembly, Plug-In
1015000
N/A
N/A
N/A
N/A
N/A
58.
Remote Room Temperature Sensor (optional)
1302024
1302024
1302024
1302024
1302024
1302024
59.
Time Clock Module (optional)
1301014
1301014
1301014
1301014
1301014
1301014
