6
Product Description
All of the plastic parts of our UV lights are manufactured from poly-
carbonate a known UV resistant material. All systems are equipped with
an 18 foot (6m) cord and molded on plug. All used materials are safe
against UV radiation. UV light bulbs average about 4000hr. use-ful life.
Install instructions (Picture 1)
Close all water lines to and from the lter unit and turn it o. Un-screw
the transparent plastic cover on the lter system Speedclean. Then put
the UV system in the hole and tighten it by hand. Do not forget to insert
the provided sealing ring in the screw cap. (See pic-ture)
Maintenance
In order to keep the UVC apparatus working properly you must clean
the intake and discharge connections and the quartz sleeve (2) 2-3
times a year. To do this, rst switch o the power supply to the UVC
apparatus and to the pump unit. Carefully remove the quartz sleeve
from the bulb and cap, cord assembly. Wash the quartz sleeve with
lukewarm soapy water and rinse thoroughly. Remove any lime scale
with vinegar, and rinse thoroughly. (It is important that you do not touch
the UV light bulb; the small amount of oil that is naturally on your skin
will ruin the bulb. If you do touch the bulb, clean it with rub-bing alcohol
before resuming service). The eective service life of the UVC lamp
is approx. 4000 burning hours. If used continuously the UVC lamp will
therefore last for an entire pond/pool season. We recommend that you
replace the UV bulb every spring.
When carrying out any maintenance the unit must be unplugged from
the electrical outlet. Always remove the intake and discharge hoses and
drain the water before cleaning. When algae densities are very high in
your pond the unit should be cleaned regularly every 3-5 days until the
problem is under control. When reassembling make sure the o-rings
are properly seated on the quartz sleeve. A small amount of petroleum
jelly can be used for lubrication if necessary. The UVC bulbs should
be replaced every season to guarantee e-cient operation. During the
winter season when temperatures fall be-low 50 degrees F (December
to mid-March) you should remove the apparatus to prevent it from
freezing.
Important Note
Technical Data
■ Product Name 18W UV Clarier
■ Model A402E-18W
■ Bulb Wattage 18 W
■ Power Supply 230 V/50 Hz
■ Average UV Output (W) 4,2
■ Life span (Std.) approx. 4000
■ Max. Pond/Pool Size (l) 20000
■ Max. Pump ow rate (l/h) 7000
■ Max. Working Pressure (bar) 1,0
Cleaning
Switch o the appliance and unplug the power cord before cleaning.
Use conventional cleaning products. Do not use solvent-based or abra-
sive cleaning agents/tools, i.e. no hard sponges, brushes etc..
Storage
The product must be thoroughly dried after cleaning. When the product
is not being used, store it in a well ventilated place out of direct sunlight.
Avoid direct sunlight. Make sure the room temperature is above 5°C in
winter.
Disposal
Disposing of packaging: The packaging material has been selected
in view of environmental concerns and disposability and is therefore
recyclable. The paper and cardboard can be recycled, as can the plastic
coverings.
Disposing of the product: Applicable in the European Union
and other European states with systems in place for collec-
ting and sorting recyclable materials. Dispose of the product
in accordance with any laws and regulations applicable at
your place of residence.
Old devices must not be placed in the household waste!
Should the device become unusable, each customer is le-
gally obligated to separate old devices from the house-
hold waste, e.g. take the device to your community/ area
collection point. It is therefore ensured that old devices are
professionally recycled and negative eects on the environ-
ments are mitigated. For this reason, electrical devices are
marked with the symbol depicted here.
Warranty conditions
The respective country’s legal provisions for warranty conditions shall
apply accordingly.
This product is tested before delivery, if properly used and maintained,
it oers you years of satisfaction. In the unfortunate event that our ma-
terial or our professional work should show defects during the warranty
period, please contact your local dealer. The warranty is invalid in case
of:
■ The plant was dismantled
■ Flammable liquids, solvents, chemicals or abrasive solutions are
being pumped
■ Obvious abuse or misuse was made
■ The product labeling has been falsied or removed from the pump
Declaration of conformity (CE)
The EU declaration of conformity can be requested via the address
shown at the end of this manual.
