Steinbach Classic 310 - Filter Shaft; Description of the Filter System; Modes of the Filter System

1
040310
Modell:
A
B
C
310 mm
605 mm
525 mm
040340
C
B
A
365 mm
665 mm
555 mm
Filter shaft
A lter sha is required if the pool is parally or enrely installed in the
ground so you can place the pump of the lter system below the pool's
water level.
- Make sure that the lter sha cannot be ooded and that ambient and rainwater can
drain away easily.
You can do so by installing a gravel layer at the boom of the sha. An oponal
immersion pump with a oat switch that is connected to a canal or drain addionally
protects your lter system from rising water inside the sha.
- Ensure sucient natural venlaon of the sha to prevent condensaon.
- Design the size of the lter sha so that you can carry out work on the lter system.
Description of the filter system
Modes of the filter system
Your lter system has several modes. They are indicated by numbers on the valve head.
1. Filter
2. Rinse
3. Circulate
4. Backush
5. Closed
6. Drain
7. Winter
The individual modes are described below.
