– 9 –
The Default Routing of signals from Nuendo to DS2416
There are sixteen separate “lines” from Nuendo to the DS2416. In VST,
these appear as Output Buses (see page 6). In the DSP Factory Input
Console window, the “lines” from Nuendo are by default connected to
DS channel 1 to 16, as follows:
•
Please note that the Output assignment (PCI 1/2 etc) for each Output
Bus can be changed, as described on page 36.
To avoid confusion, we recommend that you keep the default order of the outputs.
VST Output (and default Output Bus) DS2416 Channel
DS2416 #1 PCI 1/2 DS Channel 1
DS2416 #1 PCI 1/2 DS Channel 2
DS2416 #2 PCI 3/4 DS Channel 3
DS2416 #2 PCI 3/4 DS Channel 4
.
.
.
.
.
.
DS 2416 #8 PCI 15/16 DS Channel 15
DS 2416 #8 PCI 15/16 DS Channel 16
