STEINEL HL 1610 S User Manual

- 14 -
English
white
black
2:1
green
red
red
blue
blue
yellow
yellow (fuse)
Wiring Diagram HG 2310 LCD
7
1314 12
2
10
9
3
6
8
11
5
Part No.
Pos.
02823
02423
02621
02629
02723
02523
—
02829
02323
02225
02123
02426
1 + 2
3
4
5
6 + 8
7
9
10
11
12
13
14
HG 2310 LCD, Type 3483
Housing Set
incl. Labels
Switch with Markings (external)
Softgrip
Rubber Soft Stand
Power Cord with Strain Relief
Outlet Protection Tube
Power Cord Connector
Set of 5 Housing Screws
PCB/IC Block with Switch and Controls
Motor/Fan Assembly
Heating Element 1600W/120V
Switch (internal)
Spare Parts List HG 2310 LCD
14
HL1610S_USA 20.05.2005 15:40 Uhr Seite 15
