STEINEL IR 180 COM1 User Manual

- 32 - - 33 -
12� Troubleshooting
Malfunction Cause Remedy
Light does not switch ON
n No supply voltage
n Lux setting too low
n No motion being
detected
n Check supply voltage
n Slowly increase lux set-
ting until light switches
ON
n Ensure unobstructed
sensor vision
n Check detection zone
Light does not switch OFF
n Lux setting too high
n Stay-ON time still
eective
n Interfering heat sources:
e.g. fan heater, open
doors and windows,
pets, light bulb / halo-
gen floodlight, moving
objects
n Position Wi-Fi device
very close to the sensor
n Reduce lux setting
n Wait until stay-ON time
elapses; reduce stay-
ON time if necessary
n Use stickers to mask
out stationary sources
of interference
n Increase distance
between Wi-Fi device
and sensor >3m
Sensor switches OFF
despite persons being
present
n Stay-ON time too short
n Light-level threshold too
low
n Increase stay-ON time
n Change twilight setting
Sensor does not switch
OFF quickly enough
n Stay-ON time too long n Reduce stay-ON time
Sensor does not switch
ON quickly enough when
approached from the front
n Reach is reduced when
approached from the
front
n Install additional sensors
n Reduce distance
between two sensors
Sensor does not switch
ON when persons are
present despite it being
dark
n Lux setting too low n Sensor deactivated by
switch/button?
n Semi-automatic mode?
n Increase light-level
threshold
Switch not working
n Switch deactivated? n Check DIP switch 3
setting
11� Technical specifications
Dimensions W×H×D 80×80×50 mm
Supply voltage 220-240 ~V / 50/60 HZ
Sensor system Passive infrared (IR) / high-frequency (HF)
Reach IR max. 20 m (tangential) /
max. 4 m (radial) / HF max. 8 m
*
Angle of coverage 180°
Output Incandescent / halogen lamp load
Fluorescent lamps, electronic ballast
Fluorescent lamps, uncorrected
Fluorescent lamps, series-corrected
Fluorescent lamps, parallel-corrected
Low-voltage halogen lamps
LED < 2 W
2 W < LED < 8 W
LED > 8 W
Capacitive load
2000 W
1000 W
1000 VA
400 VA
500 VA
2000 VA
100 W
300 W
600 W
176 μF
Output, switching
output 2 presence
(COM 2 only)
max. 230 W / 230 V
max. 1 A (cos φ = 1)
for HVAC (heating/ventilation / air-conditioning)
Light-level setting 10-1000 lux, ∞ / daylight
Switching output 1 30 s - 30 min, pulse mode (approx. 2 s),
Time setting, IQ mode time (automatic adjustment to
usage profile)
Switching output 2
only COM2 for HVAC
Time setting 0 or 10 min switch-ON delay.
5-15 min stay-ON time via (RC)
1 min - 2 h stay-ON time via Smart Remote
Automatic room surveillance
Mounting height 1.1 m
Time setting 30 s - 30 min
IP rating IP20
Temperature range 0°C to 40°C
* At extreme angles, the reach of the HF 180 is extensively determined by local
conditions.

STEINEL IR 180 COM1 Specifications

General

Sensor type	Passive infrared (PIR) sensor
Learn button	Yes
Detection distance	20 m
Connectivity technology	Wired
Bulb type	Halogen
Placement	Indoor
Mounting type	Wall
Product color	White
Detection angle	180 °
Housing material	Plastic
Duration adjustment	30 - 18000 s
Installation height (max)	1.2 m
Installation height (min)	1.1 m
International Protection (IP) code	IP20
Input voltage	220 - 240 V
Input frequency	50/60 Hz
Power consumption (typical)	2000 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	30 mm
Height	80 mm
