Applications
(F) Soft soldering: First, clean
metal parts you want to join.
Then, using hot air, heat the point
you want to solder and offer up
the soldering wire. Use flux or a
soldering wire with a flux core to
prevent oxide forming.
(G) Welding and joining plastic:
All parts being welded must be of
the same plastic material. Use an
appropriate welding rod.
(H) Hot-tool welding on plastic
pipes or rods. The ends are
pressed against a coated hot tool
and then joined together.
Here are some of the applications
you can use STEINEL hot air
guns for. This selection is by no
means exhaustive – no doubt you
can immediately think of other ex-
amples.
(A) Stripping paint: Paint is soft-
ened and can be removed with a
stripping knife and paint scraper
to leave a clean surface.
(B) Shrinking tubing on cables:
The shrink tubing is slipped over
the section you want to insulate
and heated with hot air. The tub-
ing shrinks by approx. 50 % in
diameter to give a sealed union.
Shrinking is particularly fast and
even using reflector nozzles.
Sealing and stabilising cable
breaks, insulating soldered joints,
gathering cable runs, sheathing
terminal blocks.
(C) Forming PVC: Sheeting,
piping or mouldings can be soft-
ened and formed with hot air.
(D) Shaping: Ski boots and
sports shoes can be shaped for a
perfect fit.
(E) De-soldering: Electronic com-
ponents are detached quickly and
neatly from circuit boards with a
reduction nozzle.
(I) Joining sheeting: The sheets
are overlapped and welded
together. A slit nozzle is used to
direct hot air under the overlap,
then the two sheets are firmly
pressed together with a feed
roller. Also possible: Repairing
PVC tarpaulins by overlap weld-
ing with a slit nozzle.
(J) Accessories
Your dealer has a wide range of accessories for you to choose from.
- 11 -
Rigid PVC
Plasticised
PVC
Soft PE
(LDPE)
Polyethylene
Hard PE
(HDPE)
Polyethylene
PP
Polypropylene
ABS
Pipes, fittings, sheets, building pro-
files, technical mouldings
Welding temperature 300 °C
Floor coverings, wallpapers,
hoses, sheets, toys
Welding temperature 400 °C
Domestic and electrotechnical
articles, toys
Welding temperature 250 °C
Baths, baskets, canisters, insulat-
ing material, pipes
Welding temperature 300 °C
HT drainage pipes, moulded
seats, packaging, car components
Welding temperature 250 °C
Car components, equipment
housings, cases
Welding temperature 350 °Cr
Carbonises in the flame, pungent odour;
crashing sound
Smoking, yellowish-green flame,
pungent odour; silent
Light yellow flame, drips continue to
burn, smells of a candle being extin-
guished; dull sound
Light yellow flame, drips continue to
burn, smells of a candle being extin-
guished; crashing sound
Bright flame with a blue core,
drips continue to burn, pungent odour;
crashing sound
Black, fluffy smoke, sweet odour;
crashing sound
Material Application types Distinguishing characteristics
Large reflector nozzle
Prod. no. 073015
Surface nozzle, 75 mm
Prod. no. 070212
Wide-slit nozzle
Prod. no. 074715
Soldering reflector nozzle
Prod. no. 074616
Reduction nozzle,
9 mm
Prod. no. 070618
Reduction nozzle,
14 mm
Prod. no. 070717
Reduction nozzle,
20 mm
Prod. no. 070816
Reflector nozzle
Prod. no. 070519
Paint scraper kit
Prod. no. 010317
Feed roller
Prod. no. 012311
Welding nozzle
Prod. no. 070915
Heat reflector nozzle,
80 mm
Prod. no. 072117
Slit nozzle
Prod. no. 071011
Shrink tubings
Prod. no. 071417
Plastic welding wire
Rigid PVC: Prod. no. 073114
Plasticised PVC:
Prod. no. 073213
LDPE: Prod. no. 073312
HDPE: Prod. no. 071219
PP: Prod. no. 073411
ABS: Prod. no. 074210
Window nozzle, 50 mm
Prod. no. 070311
Window nozzle, 75 mm
Prod. no. 070410
Surface nozzle, 50 mm
Prod. no. 070113
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Shrink tubings
Prod. no. 071418
19
Read and observe this informa-
tion before using the tool.
Failure to observe the operating
instructions may result in the
tool becoming a source of
danger.
When using electric power tools,
observe the following basic safety
precautions to avoid electric
shock and the risk of injury and
fire. Fire may be caused if the tool
is not used with care.
Take ambient conditions
into account.
Do not expose electric power tools
to rain.
Do not use electric power tools
when they are damp or in a damp
or wet environment.
Exercise care when using the tool
in the proximity of flammable
materials. Do not direct hot air
onto the same spot for any pro-
longed period.
Do not use in the presence of an
explosive atmosphere.
Heat may be conducted to flam-
mable materials that are out of
sight.
Protect yourself from
electric shock.
Avoid touching earthed objects,
such as pipes, radiators, cookers
or refrigerators. Do not leave the
tool unattended while in operation.
Store your tools is
a safe place.
Place tool on stand after use and
allow to cool before putting is away.
Tools that are not in use should be
stored in a dry, locked room and
out of the reach of children.
Do not overload your
tools.
Work results and safety will be
enhanced if you stay within the
specified output range.
After using the tool for a prolonged
period at maximum temperature,
you should reduce the tempera-
ture before switching the tool off.
This will prolong the life of the
heating element.
Do not carry the tool by the power
cord. Do not unplug the tool by
pulling on the power cord. Protect
the power cord from heat, oil and
sharp edges.
Beware of toxic gases
and fire hazards.
Toxic gases may occur when
working on plastics, paints, var-
nishes or similar materials. Beware
of fire and ignition hazards.
For your own safety, only use
accessories and attachments that
are specified in the operating
instructions or recommended or
specified by the tool manufacturer.
Using attachments or accessories
other than those recommended in
the operating instructions or cata-
logue may result in personal
injury.
Repairs must only be
carried out by a
qualified electrician.
This electric power tool complies
with the relevant safety regulations.
Repairs must only be performed
by a qualified electrician, other-
wise the user may run the risk of
accidents.
Keep these safety warnings in a
safe place.
Safety warnings
Functional guarantee
This STEINEL product has been manufactured with the utmost care, tested for proper operation and safety
in accordance with applicable regulations and then subjected to ramdom sample inspection. STEINEL guar-
antees that it is in perfect condition and proper working order. The product is guaranteed for 12 months or
500 hours of operation commencing on the date of sale to the consumer. We will remedy defects caused by
material flaws or manufacturing faults. The guarantee will be met by repair or replacement of defective parts
at our own discretion. This guarantee does not cover damage to wearing parts, damage or defects caused
by improper treatment or maintenance nor does it cover breakage as a result of the product being dropped.
Further consequential damage to other objects is excluded. Claims under the guarantee shall only be accept-
ed if the product is sent fully assembled and well packed complete with sales slip or
invoice (date of purchase and dealer's stamp) to the appropriate Service Centre or hand-
ed in to the dealer within the first 6 months. Repair Service: Our customer service depart-
ment will repair any faults not covered by the guarantee or occurring after the guarantee
has expired. Please send the product well packed to the Service Centre.
!
