Technical Specifications
Sensor-switched
LED floodlight XLed FL-50 XLed FL-100
Dimensions (h x w x d): 182 x 175 x 541 mm 182 x 175 x 1041 mm
Output: 9 LEDs, approx. 25 W 9 LEDs, approx. 25 W
Power supply: 230-240 V/50 Hz 230-240 V/50 Hz
Light colour approx. 3500 Kelvin (warm white) approx. 3500 Kelvin (warm white)
Luminous flux: 820 lumens (approx. 42 lm/W) 820 lumens (approx. 42 lm/W)
Colour rendering index: RA ≥ 90% RA ≥ 90%
Max. additional
switching capacity: 16 floodlight projectors
Incandescent lamps, 800 W max. at 230 V AC
Fluorescent lamp, 400 W max., at cos ϕ = 0.5,
inductive load at 230 V AC
Fluorescent lamps, low-energy bulbs,
LED lights with electronic ballast operating on 230 V AC,
max. of 4 x 60 W each, C ≤ 88 μF
LED life expectancy: up to 50,000 hours up to 50,000 hours.
Area light is projected on: 285 m
2
385 m
2
Floodlight adjustment range: 180° (tilting) 180° (tilting)
120° (turning) 120° (turning)
Twilight setting: 2 – 100 lux 2 – 100 lux
Weight: 2.2 kg 2.5 kg
Temperature range: -20 °C to +50 °C -20 °C to +50 °C
IP rating: IP 44 IP 44
Protection class I I
Functional Warranty
This STEINEL product has been manufactured with
utmost care, tested for proper operation and safety
and then subjected to random sample inspection.
STEINEL guarantees that it is in perfect condition and
proper working order.
The warranty period is 3 years and starts on the date
of sale to the consumer. We will remedy defects
caused by material flaws or manufacturing faults.
The warranty will be met by repair or replacement of
defective parts at our own discretion. The warranty
shall not cover damage to wear parts, damage or
defects caused by improper treatment or mainten-
ance. Further consequential damage to other objects
shall be excluded.
Claims under the warranty will only be accepted if the
light is sent fully assembled and well-packed with a
brief description of the fault, a receipt or invoice (date
of purchase and dealer's stamp) to the appropriate
Service Centre.
Repair service:
If defects occur outside the warranty
period or are not covered by warran-
ty, ask your nearest service station
for the possibility of repair.
Declaration of Conformity
This product complies with
- Low-Voltage Directive 2006/95/EC
- EMC Directive 2004/108/EC
- RoHS Directive 2011/65/EC
- WEEE Directive 2012/19/EC
Troubleshooting
Sensor-switched LED floodlight
without power
Sensor-switched LED floodlight
will not switch ON
Sensor-switched LED floodlight
will not switch OFF
Malfunction
■ Fuse has blown; not switched
ON; break in wiring
■ Short circuit
■ New fuse, turn on power switch,
check wiring with voltage tester
■ Check connections
■ Check connection
■ Twilight setting in night-time
mode during daytime operation
■ Mains power switch OFF
■ Fuse faulty
■ Timer not switching ON/OFF or
manual override not functioning
■ Adjust setting
■ Switch ON
■ Replace fuse, check connection
if necessary
■ Check timer/manual override
■ LDR sensor covered/dirty ■ Check/clean
Cause Remedy
