TMAX™ Owner’s Manual
TMAX3 Mounting Kit - Tandem Axle - PN 31143
88.69
133.69
PN 31143
.25
TYP 2
TO BODY
DO NOT
WELD TO
TRUCK FRAME
7
MEASUREMENT FROM CENTER OF
1
2
2
4
5
11
12
8
8
6
AXLE TO FRONT MOUNTING HOLE
3
5
1
4
5
1
2
MEASUREMENT FROM CENTER OF
AXLE TO REAR MOUNTING HOLE
.YTQNOITPIRCSEDTRAPMETI
14543 CAP SCR 0.75-10X2.00 HHGR8 ZY 6
2C6219 WASHER 0.75 SAE FLAT YELLOW GR812
3C0538 NUT 0.75-10 HHGR8 NYLOC 6
4C1025 CAP SCR 0.63-11X2.00 HHGR8 ZY 20
5C5902 WASHER 0.63 SAE FLAT YELLOW GR840
02COLYN HH 11-36.0 TUN62826
79904SHEAR PLATE 0.50X9.00X12.002
200.03X05.2X83. TALF358518
2YDOB 3T RAEHS ETALP775429
10 27281PLATE REINF SHEAR T3 BODY 2
11 24639BRACKET BODY MOUNT T3 BODY 2
12 13951PCBRKT WLDMT BOTTOM BODY MNT T2 4
IMPORTANT NOTE: DO NOT OVER SIZE MOUNTING
HOLES IN CHASSIS FRAME.
BEHIND REAR SPRING SHACKLE.
REAR. HOLD FLUSH WITH REAR WHEN
INSTALLING AND WELD TO TRUCK FRAME
USE PN 15853 .38 X 2.50 FLAT AS SPACER
ON CHASSIS WITH DOUBLE FRAME
RAILS THAT DO NOT EXTEND TO
