Stellar
®
TMAX™ Owner’s Manual | Page 21
Ctrl Pkg E-Link 2.0 Conn Diagram - 85450
ELINK PDM ASM #84984
TO COMPRESSOR
TO BATTERY-
CHASSIS GND
TO FRAME STUD
BAT HOT
JUNCTION
C
E
D
F
B
A
TO REAR HRN
S
#75538
-BODY/TUNNEL-
100A MAIN BRKR #75316
(MOUNT WITHIN 18 INCHES
OF CHASSIS BATTERIES)
-
C
R
A
N
E
C
O
M
P
T
-
CHASSIS
PIGTAIL
#74666
BODY POWER
HARNESS
#98624
ACCESORY CIRCUITS
FLOOD LIGHTS
BEACON LIGHT
ACCESORY 1
ACCESSORY 2
RMT SPEED CTRL (09)
PARK BRAKE (17)
PTO LIGHT (45)
ENGINE STOP (27)
ENGINE START (26)
IGNITION (37)
PTO (D1)
SPEED CTRL (08)
TO CHASSIS RPM (CRANE)
CHASSIS PARK BRAKE (-) SIG
PTO PRESS SW (-) SIG
TO CHASSIS ENGINE STOP
TO CHASSIS ENGINE START
CHASSIS IGNITION (+12V)
PTO (+) OUTPUT
TO CHASSIS RPM (CPRSR)
TO BATTERY+
ELINK BODY
HARNESS #98623
-CHASSIS INTEGRATION-
GND JUNCTION
(MOUNTING SCREW)
