stellar labs TMAX16K - Page 30

Page 22 | Stellar
®
TMAX™ Owner’s Manual
Ctrl Pkg VEC Front Switch Panel - 34535
TO CPRSR
SPARE ACCESORY CIRCUITS
BEACON LIGHT LH FLOOD LIGHT RH FLOOD LIGHT
C
E
D
F
B
A
CHASSIS
PIGTAIL
#74666
RMT SPEED CTRL (09)
PARK BRAKE (17)
PTO LIGHT/ STOP B (45)
ENGINE STOP (27)
ENGINE START (26)
IGNITION (37)
PTO (D1)
SPEED CTRL (08)
TO CHASSIS RPM (CRANE)
CHASSIS PARK BRAKE (-) SIG
TO CHASSIS ENGINE STOP A
TO CHASSIS ENGINE START
CHASSIS IGNITION (+12V)
PTO (+) OUTPUT
TO CHASSIS RPM (CPRSR)
TO REAR HRNS
#75538
BODY HARNESS
#34109
LOAD
B+
AUX TRAILER
SPARE 1 OUT
TROUBLE LIGHT
TO BATTERY+
100A SS
SOLENOID
#72036
-BODY/TUNNEL-
TO VEC BOX
-
C
R
A
N
E
C
O
M
P
T
-
-CHASSIS INTEGRATION-
CHASSIS GND
TO FRAME STUD
BLACK- GROUND
RED- BATTERY+
TO CHASSIS ENGINE STOP B
