TMAX™ Owner’s Manual | Page 25
Light Pkg 16K-11 Mech Body FMVSS & Compt - 120579
D
E
F
C
A
B
C
D
A
B
A
B
C
D
C
U
R
B
S
T
R
E
E
T
C
D
A
B
A
B
C
D
MARKER
LIGHTS
OPTIONAL
SURFACE MOUNT
BU ALARM
UNDER BODY
BU ALARM
OPTIONAL
FLOOD
REVERSE
TAIL/
BRAKE
GROUND
STUD
MARKER LIGHTS
IN BUMPER
LICENSE PLATE
LIGHT
TO BODY
HARNESS
36" LIGHT STRIP
#74724
36" LIGHT STRIP
#74724
*BUTT CONNECT TO
CHASSIS FACTORY
TAIL LIGHT HARNESS
CABLE EXT
#75721
CABLE EXT
#75721
REAR HARNESS
MECH V2
#75538
TAIL LIGHT
HARNESS
#85371
CS TAIL LIGHT BOX
SS REAR
CS REAR
HORIZONTAL STRUCTURAL TUBE
HORIZONTAL STRUCTURAL TUBE
RED & YEL
(IN TAIL LT)
GRY
(IN TAIL LT)
MARKER
LIGHTS
OPTIONAL
FLOOD
REVERSE
TAIL/
BRAKE
SS TAIL LIGHT BOX
RED & YEL
(IN TAIL LT)
GRY
(IN TAIL LT)
18" LIGHT STRIP
#74723
18" LIGHT STRIP
#74723
OPTIONAL
FLOOD LIGHT
CS HORIZ
36" LIGHT STRIP
#74724
36" LIGHT STRIP
#74724
OPTIONAL
FLOOD LIGHT
MARKER LIGHT ON
FRONT OF BODY
SIDE PACK HARNESS
#74722
OPTIONAL
FLOOD LIGHT
OPTIONAL
COMPT LIGHT
(NOT USED)
CS1V
CS2V
CURB SIDE
OPTIONAL
COMPT LIGHT
(NOT USED)
36" LIGHT STRIP
#74724
18" LIGHT STRIP
#74723
18" LIGHT STRIP
#74723
OPTIONAL
FLOOD LIGHT
OPTIONAL
FLOOD LIGHT
MARKER LIGHT ON
FRONT OF BODY
OPTIONAL
FLOOD LIGHT
SIDE PACK HARNESS
#74722
36" LIGHT STRIP
#74724
SS HORIZ
SS1VR
SS1VF
STREET SIDE
*PLUG LIGHT #120577 INTO THE TAIL/ BRAKE PLUG.
*BUTT CONNECT THE RED & YELLOW WIRES TO THE BODY
OPTION WIRE FOR REAR STROBES.
*CUT THE REVERSE WIRE (23) & 2-1 BUTT CONNECT THE GRAY
WIRE BACK INTO THE REVERSE CIRCUIT.
*PLUG LIGHT #120577 INTO THE TAIL/ BRAKE PLUG.
*BUTT CONNECT THE RED & YELLOW WIRES TO THE BODY
OPTION WIRE FOR REAR STROBES.
*CUT THE REVERSE WIRE (63) & 2-1 BUTT CONNECT THE GRAY
WIRE BACK INTO THE REVERSE CIRCUIT.
NOTE:
*USE HARNESS RETAINER KIT #94545 IN THE REAR COMPARTMENTS TO FASTEN THE
REAR HARNESS
*USE LOOM CLIPS #88453 TO FASTEN SIDEPACK HARNESSES.
*USE GROMMETS IN ALL LOCATIONS WHERE HARNESSES ENTER/ EXIT THE BODY.
*FLOOD LIGHT MAX AMPERAGE PER SIDE IS 10 AMPS
*NO MORE THAN 5 AMP LOAD TO BE CONNECTED TO ANY SINGLE FLOOD LIGHT WIRE
LOCATION
