Stellar
®
TMAX™ Owner’s Manual | Page 31
Light Kit Compt Kit V2 TMAX LP-14 - 75748
D
E
F
C
A
B
C
D
A
B
A
B
C
D
C
U
R
B
S
T
R
E
E
T
C
D
A
B
A
B
C
D
OPTIONAL
SURFACE MOUNT
BU ALARM
UNDER BODY
BU ALARM
OPTIONAL
FLOOD
REVERSE
STOP/
TURN/ TAIL
GROUND
STUD
MARKER LIGHTS
IN BUMPER
OPTIONAL
STROBE
LICENSE PLATE
LIGHTS
18" LIGHT STRIP
#74723
18" LIGHT STRIP
#74723
OPTIONAL
FLOOD LIGHT
CS HORIZ
36" LIGHT STRIP
#74724
OPTIONAL COMPT LIGHT
(NOT USED)
36" LIGHT STRIP
#74724
36" LIGHT STRIP
#74724
OPTIONAL
FLOOD LIGHT
CABLE EXT
#75721
MARKER LIGHT ON
FRONT OF BODY
REAR HARNESS
MECH LP
#94648
TAIL LIGHT
HARNESS
#85371
SIDE PACK HARNESS
#74722
SS BUMPER
CS BUMPER
OPTIONAL
FLOOD LIGHT
CS REAR
HORIZONTAL STRUCTURAL TUBE
CS1V
CS2V
STOP/
TURN/ TAIL
REVERSE
OPTIONAL
FLOOD
CURB SIDE
*IF SIDE PACK IS ON THE STREET SIDE, USE
THIS PLUG IN SS REAR COMPT FOR
36" LIGHT STRIP #74724
REAR
MARKER
OPTIONAL
STROBE
REAR
MARKER
36" LIGHT STRIP
#74724
NOTE:
*IF SIDE PACK IS ON THE STREET SIDE, REVERSE SIDE PACK HARNESS AND MARKER
LIGHT HARNESS.
*USE HARNESS RETAINER KIT #94545 IN THE REAR COMPARTMENTS TO FASTEN THE
REAR HARNESS
*USE LOOM CLIPS #88453 TO FASTEN SIDEPACK HARNESSES.
*USE GROMMETS IN ALL LOCATIONS WHERE HARNESSES ENTER/ EXIT THE BODY.
*FLOOD LIGHT MAX AMPERAGE PER SIDE IS 10 AMPS
*NO MORE THAN 5 AMP LOAD TO BE CONNECTED TO
ANY SINGLE FLOOD LIGHT WIRE
LOCATION
SIDE
MARKER
TO BODY
HARNESS
*BUTT CONNECT TO
CHASSIS FACTORY
TAIL LIGHT HARNESS
SIDE
MARKER
CABLE EXT
#75721
MARKER LT WHIP
#113838
HORIZONTAL STRUCTURAL TUBE
MARKER LIGHT ON
FRONT OF BODY
STREET SIDE
