Page 38 | Stellar
®
TMAX™ Owner’s Manual
Right Tailgate Arm Assembly - PN 75917
4
7
9
14
9
11
5
18
3
16
7
9
11
9
9
7
6
10
8
9
14
7
9
14
14
9
11
13
17
15
12
1
2
.YTQNOITPIRCSEDTRAPMETI
1 0333 NUT 0.25-20 HHGR5 NYLOC 1
2KCOL 83.0 REHSAW32502
25RGHH 61-83.0 TUN53503
4 15846 BRKT TAILGATE STOP FOLD DOWN1
1HR TNUOM ETAGLIAT TKRB748515
6 15849 BRKT TAILGATE WLDMT STOP 1
4SS COLYN HH 31-05.0 TUN461227
8 22165 NUT 0.50-13 HH JAM NYLOC SS 1
8SS TALF SSU 05.0 REHSAW861229
10 22169STUD .50-13X4.00X1.75THRD1
11 22170CAP SCR 0.50-13X1.50 HHGR5 SS 3
12 41047 WASHER 0.25 BONDED SEALING NEO BACK 1
13 66182 WASHER 0.38 BONDED SEALING NEO BACK 2
14 C4516WASHER 0.56IDX1.50ODX0.13 THK NYLON4
15 C4726BUMPER RUBBER 1.00 W/WASHER 0.531H 1
16 C5587CAP PLASTIC 0.375IDX0.50ODX2.00LONG1
17 C6022CAP SCR 0.25-20X1.00 BTNHD SS 1
18 D1482 BOLT CARRIAGE 0.38-16X1.25 SS 2
PN 75917
