TMAX™ Owner’s Manual
TMAX Service Body Specifications
TMAX™30K-9
Applicable Chassis
19.5” Dual Rear Wheels on
14,000 – 22,900 GVWR
Clear Cab to Axle 60” (152.4 cm)
Body Length 109” (276.9 cm)
Body Height (Steel)
• CS1V Raised to 60” (152.4 cm)
remaining 44” (111.76 cm)
• All Raised 52” (132.08 cm)
• All Raised 52” (132.08 cm) with
8” (20.32 cm) drop well in CS1V
Body Height (Aluminum)
• All Raised 52” (132.08 cm)
• All Raised 52” (132.08 cm) with
8” (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
EC3200, EC4000, EC5000,
3315, 4421, 5521, 6521
TMAX™16K-9
Applicable Chassis
19.5" Dual Rear Wheels on
14,000 – 22,900 GVWR
Clear Cab to Axle 60” (152.4 cm)
Body Length 109” (276.9 cm)
Body Height (Steel) Not offered in Steel
Body Height (Aluminum)
• 44" (111.76 cm)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models EC3200, EC4000, 3315, 4421
TMAX™30K-11
Applicable Chassis
19.5" Dual Rear Wheels on
14,000 – 22,900 GVWR
Clear Cab to Axle 84” (213.36 cm)
Body Length 133” (337.82 cm)
Body Height (Steel)
• 44" (111.76 cm)
• CS1V Raised to 60" (152.4 cm)
remaining 44" (111.76 cm)
• All Raised 60" (132.08 cm)
Body Height (Aluminum)
• 44" (111.76 cm)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
EC3200, EC4000, EC5000,
3315, 4421, 5521, 6521
TMAX™16K-11
Applicable Chassis
19.5" Dual Rear Wheels on
14,000 – 22,900 GVWR
Clear Cab to Axle 84” (213.36 cm)
Body Length 133” (337.82 cm)
Body Height (Steel) Not offered in Steel
Body Height (Aluminum)
• 44" (111.76 cm)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models EC3200, EC4000, 3315, 4421
TMAX™1-9
Applicable Chassis
19.5" Dual Rear Wheels on
16,000 – 22,900 GVWR
Clear Cab to Axle 60” (152.4 cm)
Body Length 109" (276.86 cm)
Body Height (Steel)
• 44" (111.76 cm)
• CS1V Raised to 60" (152.4 cm)
remaining 44" (111.76 cm)
Body Height (Aluminum)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
EC3200, EC4000, EC5000, EC6000, 3315,
4421, 5521, 6521, 7621, 7630, 8621, 8630
TMAX™1-11
Applicable Chassis
19.5" Dual Rear Wheels on
16,000 – 22,900 GVWR
Clear Cab to Axle 84” (213.36 cm)
Body Length 133” (337.82 cm)
Body Height (Steel)
• 44" (111.76 cm)
• CS1V Raised to 60" (152.4 cm)
remaining 44" (111.76 cm)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Height (Aluminum)
• 44" (111.76 cm)
• All Raised 52" (132.08 cm)
• All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
• All Raised 60" (152.4 cm)
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
EC3200, EC4000, EC5000, EC6000, 3315,
4421, 5521, 6521, 7621, 7630, 8621, 8630
