TMAX™ Owner’s Manual | Page vii
TMAX™2-11
Applicable Chassis
22.5" Dual Rear Wheels on
21,000 – 33,000 GVWR
Clear Cab to Axle 84" (213.36 cm)
Body Length 133" (337.82 cm)
Body Height (Steel) All Raised 60" (152.4 cm)
Body Height (Aluminum) All Raised 60" (152.4 cm)
Body Width 94" (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
7621, 7630, 8621, 8630, 9621, 9630,
10621, 10630, 12621, 12630
TMAX™2-14
Applicable Chassis
22.5" Dual Rear Wheels on
21,000 – 33,000 GVWR
Clear Cab to Axle 120" (304.8 cm)
Body Length 169" (429.26 cm)
Body Height (Steel) All Raised 60" (152.4 cm)
Body Height (Aluminum) All Raised 60" (152.4 cm)
Body Width 94" (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
7621, 7630, 8621, 8630, 9621, 9630,
10621, 10630, 12621, 12630
TMAX Service Body Specifications (cont.)
TMAX™3S-14
Applicable Chassis
22.5" Dual Rear Wheels on
33,000 GVWR and up
Clear Cab to Axle 120" (304.8 cm)
Body Length 169" (429.26 cm)
Body Height (Steel) All Raised 60" (152.4 cm)
Body Height (Aluminum) All Raised 60" (152.4 cm)
Body Width 96" (243.84 cm)
Compartment Depth 22” (55.88 cm)
Crane Models 14530
TMAX™3T-17.5
Applicable Chassis
22.5" Dual Rear Wheels on Tandem
Chassis 33,000 GVWR and up
Clear Cab to Trunnion 138" (350.58 cm)
Body Length 210" (533.40 cm)
Body Height (Steel) All Raised 60" (152.4 cm)
Body Height (Aluminum) All Raised 60" (152.4 cm)
Body Width 96" (243.84 cm)
Compartment Depth 22” (55.88 cm)
Crane Models 14530
TMAX™LP-12
Applicable Chassis
19.5" Dual Rear Wheels on
15,000 – 22,900 GVWR
Clear Cab to Axle 84” (213.36 cm)
Body Length 145" (368.3 cm)
Body Height (Steel) 44” (111.76 cm)
Body Height (Aluminum) 44” (111.76 cm)
Body Width 96" (243.84 cm)
Compartment Depth 17” (43.2 cm)
Crane Models
EC4000, EC5000, EC6000, 4421,
5521, 7621, 7630, 8621, 8630
TMAX™LP-14
Applicable Chassis
19.5" Dual Rear Wheels on
15,000 – 22,900 GVWR
Clear Cab to Axle 108” (274.32 cm)
Body Length 169" (429.26 cm)
Body Height (Steel) 44” (111.76 cm)
Body Height (Aluminum) 44” (111.76 cm)
Body Width 96" (243.84 cm)
Compartment Depth 17” (43.2 cm)
Crane Models
EC4000, EC5000, EC6000, 4421,
5521, 7621, 7630, 8621, 8630
TMAX™1-13
Applicable Chassis
19.5" Dual Rear Wheels on
22,000 – 22,900 GVWR
Clear Cab to Axle 108” (274.32 cm)
Body Length 157” (398.78 cm)
Body Height (Aluminum)
All Raised 52" (132.08 cm) with
8" (20.32 cm) drop well in CS1V
Body Width 94” (238.76 cm)
Compartment Depth 22” (55.88 cm)
Crane Models
EC3200, EC4000, EC5000, EC6000, 3315,
4421, 5521, 6521, 7621, 7630, 8621, 8630
