12
INSSFECMI1016
TABLEAU D’AJUSTEMENT DES DÉBITS D’AIR
AIRFLOW SETTINGS TABLE
MODÈLE / MODEL
2321-1
CONT. VENT. W VENT.
Y VENT.
LOW HIGH W1 W2
1 400 1200 450 1150 800
2 533 1333 710 1410 1033
3 666 1466 965 1665 1266
4 800 1600 1225 1925 1500
5 933 1733 1485 2000 1733
6 1066 1866 1740 2000 1966
7 1200 2000 2000 2000 2200
RECOMMANDÉ / RECOMMENDED
TABLEAU D’AJUSTEMENT DES DÉBITS D’AIR
AIRFLOW SETTINGS TABLE
MODÈLE / MODEL
2721
CONT. VENT. W VENT.
Y VENT.
LOW HIGH W1 W2
1 400 1200 750 1500 800
2 533 1333 992 1742 1033
3 666 1466 1233 1983 1266
4 800 1600 1475 2200 1500
5 933 1733 1717 2200 1733
6 1066 1866 1740 2200 1966
7 1200 2000 2200 2200 2200
RECOMMANDÉ / RECOMMENDED
TABLEAU D’AJUSTEMENT DES DÉBITS D’AIR
AIRFLOW SETTINGS TABLE
MODÈLE / MODEL
3021
CONT. VENT. W VENT.
Y VENT.
LOW HIGH W1 W2
1 400 1200 750 1500 800
2 533 1333 992 1742 1033
3 666 1466 1233 1983 1266
4 800 1600 1475 2200 1500
5 933 1733 1717 2200 1733
6 1066 1866 1740 2200 1966
7 1200 2000 2200 2200 2200
RECOMMANDÉ / RECOMMENDED
When the furnace has run at full capacity for 10 minutes, block the supply and return air openings and measure the supply air temperature at
a point that is not exposed to heat radiation from the elements. The elements are supposed to shut down one by one before the temperature
exceeds 95°C-200°F.
If you install a thermostat equipped with a heat anticipator, refer to the user’s guide of the thermostat to adjust it.
Using an ampmeter, measure the current on the single stage thermostat.
PROCEDURES TO FOLLOW
1. Set the anticipator to its highest setting (ineffective);
2. Disconnect the wire from the W1 terminal of the furnace and connect an ampmeter between the W1 terminal and the wire mentioned;
3. Increase the temperature set point of the thermostat in order to call for heat and let the furnace run for 3 to 4 minutes so that it reaches its
full capacity;
4. Once the current is stable, take the reading and adjust the anticipator to that value. Set the anticipator to a higher value if longer heating
cycles are required.
VERIFYING THE HIGH LIMIT THERMAL PROTECTIONS
ANTICIPATOR
