Stelpro SFECM2321 - Page 15

15
INSSFECMI1016
REPLACEMENT COMPONENT LIST
5
DETAIL B
SWIVEL PANEL HIDDEN FOR MORE CLARITY
9
7
10
DETAIL A
3
4
A
8
1
2
6
B
REF. # PART # DESCRIPTION
1 ELF-SFE0221-1 ELEMENT ASSEMBLY SFE 2.5KW/240V/1PH 11'' LONG
1 ELF-SFE0221-2 ELEMENT ASSEMBLY SFE 2.5KW/240V/1PH 14'' LONG
1 ELF-SFE0521-1 ELEMENT ASSEMBLY SFE 5KW/240V/1PH 11'' LONG
1 ELF-SFE0521-2 ELEMENT ASSEMBLY SFE 5KW/240V/1PH 14'' LONG
2 BLO-004 SQUIRREL CAGE & BLOWER 10-8
2 BLO-005 SQUIRREL CAGE & BLOWER 12-11
3 MO-034 ECM MOTOR 1/2HP
3 MO-035 ECM MOTOR 1 HP
4 SUP-002 MOTOR SUPPORT FOR BLO-005
4 SUP-004 MOTOR SUPPORT FOR BLO-004
5 PROT-045 THERMAL PROTECTION L140-40F
7 REL-021 RELAY, DPDT, 30 A, 24 VDC
8 CIR-024 ELECTRONIC BOARD FOR SFECM FURNACE
9 TRF200040D TRANSFORMER, 240-208V/24VAC/40 VA, CL.2
10 BREA-003 CIRCUIT BREAKER, 120/240 VAC, 50 A, 2 P
