API A065 series Interfacing Via bowling (MC2)/Switch pinsetters
8
PIN IN/OUT CONNECTORS DESCRIPTION
CN1 (rs232 for Lane
computer)
CN2 (rs232 for BOWLER’S CONSOLE)
2 Rx 10-11 Vdd (+12)
3 Tx 14-15 Rx1
5 Gnd 18-19 Tx1
13-24-25 Gnd
CN3 (MAIN Sciba ) CN11 (AUX Sciba ) CN12
1 Vdd (+12) 1 Vdd (+12) 1 Vdd (+12)
2 Odd Speed in 2 - 2 Odd Shoes In
3 Gnd 3 Gnd 3 Even shoes In
4 Odd trigger in 4 - 4 Gnd
5 Even trigger in 5 Even trigger in
6 Even speed in 6 Even speed in
7 RXD (rs232 line 1) 7 RXD (rs232 line 2)
8 TXD (rs232 line 2) 8 TXD (rs232 line 2)
9 Gnd 9 Gnd
1 Instant glow OUTPUT N.O. relays contact CN5
2 Instant glow OUTPUT N.O. relays contact
1 Foul signal INPUT (parallel to foul light) 12-24 AC/DC
2 Foul signal INPUT (parallel to foul light) 12-24 AC/DC
3 2
nd
ball signal INPUT (parallel to 2
nd
ball light) 12-24 AC/DC
CN6
(EVEN/ODD)
4 2
nd
ball signal INPUT (parallel to 2
nd
ball light) 12-24 AC/DC
1 Pinsetter ON (parallel to MGR switch) N.O. relays contact
2 Pinsetter ON (parallel to MGR switch) N.O. relays contact
3 Pinsetter practice (GND to pinsetter) GND to pinsetters
4 Pinsetter CYCLE (parallel to 10
th
frame switch) N.O. relays contact
CN7
(EVEN/ODD)
5 Pinsetter CYCLE (parallel to 10
th
frame switch) N.O. relays contact
1 - APS code
2 - APS code
3 - APS code
CN8
(EVEN/ODD)
4 - APS code
1 Bumper OUTPUT N.O. relays contact CN9
(EVEN/ODD)
2 Bumper OUTPUT N.O. relays contact
1 Maintenance OUTPUT N.O. relays contact CN10
(EVEN/ODD)
2 Maintenance OUTPUT N.O. relays contact
1 Odd BAR CALL OUTPUT N.O. relays contact
2 Odd BAR CALL OUTPUT N.O. relays contact
3 ODD STRIKE OUT N.O. relays contact
4 ODD STRIKE OUT N.O. relays contact
5 ODD GUTTER OUT N.O. relays contact
CN13
(ODD)
6 ODD GUTTER OUT N.O. relays contact
1 Even BAR CALL OUTPUT N.O. relays contact
2 Even BAR CALL OUTPUT N.O. relays contact
3 EVEN STRIKE OUT N.O. relays contact
4 EVEN STRIKE OUT N.O. relays contact
5 EVEN GUTTER OUT N.O. relays contact
CN13
(EVEN)
6 EVEN GUTTER OUT N.O. relays contact
1 - N.O. relays contact CN14
(EVEN/ODD)
2 - N.O. relays contact
1 Bar Call OUTPUT N.O. relays contact
CN15
2 Bar Call OUTPUT N.O. relays contact
