Page #5 background image
STEP-MAX10 Hardware Manual
5
/
7
3.2 FPGA Device
Now the STEP-MAX10 development board have two version which the only difference of is
the FPGA device.
Version
MAX10 10M02
MAX10 10M08
Series
MAX10
MAX10
Number of LABs/CLBs
125
500
Number of Logic Elements/Cells
2000
8000
Total RAM Bits
110592
387072
Number of I/O
112
112
Voltage-Supply
2.85V-3.465V
2.85V-3.465V
Package/Case
153-VFBGA
153-VFBGA
Supplier Device Package
153-MBGA(8*8)
153-MBGA(8*8)
3.3 Programming and Configuration
· On-Board USB Blaster (Normal Micro-USB connector)
3.4 Connecters
· 36 GPIO Header
3.5 Display
· 7-Segment Display ×2
· User LEDs ×8
· RGB LEDs ×2
3.6 Buttons and Switches
· Buttons ×4
· Switches ×4
3.7 Power
· 5V DC input from Micro-USB.
