ANTENNA DIRECTION CONFIGURATION
40m-6m Reflector
40m-6m Driven
40m-6m Reflector
REVERSE DIRECTION
(180 deg)
FORWARD DIRECTION (Normal)
40m-6m Director
40m-6m Driven
40m-6m Director
6m Passive Element
The driven element is a dipole when
on 40 and 30 meters
