SteppIR 3 Element Yagi - Mast Saddle Installation

39
INSTALL THE MAST SADDLES
QTY Part Number Description KEY
2 10-1021-43 Mast Plate A
4 10-1601-22 Saddle Clamp, 2” B
4 60-0066 Hex Bolt, 5/16” x 4” C
4 60-0046 Nylock Nut, 5/16 D
2 60-0017 Pan Screw, 10-32 x 3/4” E
2 60-0112 Set Screw, 10-32 x 1/4”, Cup Point F
A
A
B
B
C
B
B
C
C
C
D
D
D
D
E
E
F
F
