SUP ELECTRIC AIR PUMP
782A plus
Air pump Hose/Type-C USB ca ble Instruction Book
IV. Details of Accessories
14
VIII.Precautions
VII.Deflation operation
Remove the hose from the inflation inlet, Connect the end with flexible conduit
adaptor (11) of the hose with the air pump deflation outlet (2),
and twist clockwise to tighten it, as Figure 3, and the oher end shall still be to
the airbag.
Press the button of the power switch of air punp, and start the deflation
until all the gas is discharged, then the power can be turned off to stop the
deflation.
When not in use, turn off the power
switch “ ” , remove the hose from
the air pump and air bag and store the
product properly.(the symbol “-”on the
switch means “ON”, “o” means “OFF”).
（Figure 3)
Do not block the inflation inlet (1) and Deflation outlet (2), and ensure that the
inflation inlet (1) and Deflation outlet (2) shall remain smooth at all time.
Observe the local waste streatment provisions,and it is not allowed to throw
the air pump away randomly.
Don't use this product when the hose is damaged, and please change the
hose immediately.
Don't pull out the hose when inflating, because that the high pressure may
hurt the physical body.
Don't make the air punp work for more than 20 minutes, because that motor
overheating may cause internal damage; and the air pump shall be fully
cooled for 30 minutes after continuously working up to 20 minutes.
Please don't use tis air pump if any part is damged, and please contact
with the professional peronnel to repaiar it.
In order to prevent risk, the inflation inlet shall not be forward to face or body.
Please don't leave while inflating.
IX.Charging
I. Product Introduction
III. List of Accessories
Please make sure that the following accessories are in the box before
using it, if any missing, please contact with the local agents or distributors.
Disposal: Do not dispose of this product as unsorted municipal waste.
The waste must be collected separately for special disposal.
II. Product parameters
Pressure
Airflow
Battery
Power
Input voltage
Charging input
Noise
0-20PSI
Low: 350 L/min/ High: 70 L/min
12V/6000mAH
Rated 110 W
DC12-14.4V
USB 5 V/1 A、5 V/2 A or 12 V/1.5 A
≤90dB
Charging time
5V/1A
5V/2A
12V/1.5A
About 12 hours
About 8 hours
About 4 hours
782A Plus is an intelligent power storage air pump with preset pressure
value andIt can inflate inflatable tents, inflatable beds,
canoeing, etc. In addition, it has an intelligent pressure system. That is to
say, air pump will automatically stop inflation when pressure reaches the
preset pressure value.
It uses Type-C USB of 5V 1A, 5V 2A or 12V 1.5A for charging, where cigarette
lighter is plugged into 12V DC power supply to supply power to product, and
product shall not be started during charging.
Please use type-C USB cable with this product for charging. Charging voltage
is 5V 1A, 5V 2A or 12V 1.5A. Charging voltage shall be automatically identified
(as shown in Fig. 4)
When only one indicator is on, it is recommended to charge the product in
time. The indicators will flash during charging, and all the indicators will be
on when the product is fully charged.
