POS PART NUMBER DESCRIPTION NUM
1 8061-782102 Tail pipe 1
2 8061-782101 Central pipe 1
3 8342-782101 Pressure spring 1
4 8312-782101-00 Button 1
5 8440-782106-00 Motor blade assembly 1
5,1 8401-782001-01 Motor 1
5,2 8021-782001-01 The motor end cover 1
5,3 8SJAD04-08D Machine screw 2
5,4 8440-782002-00 Blade assembly 1
6 8006-782101-00 Housing 1
7 8020-782101-00 Decorative cover 1
8 8042-782101-00 Switch 1
9 8006-782102-00 Housing 1
10 8020-782102-00 Decorative cover 1
11 8414-782101-00 Electronic components 1
12 8SJGB40-16D Self tapping screw 14
13 8292-782107-00 Holder 1
14 8292-782108-00 Holder 1
8.3 TROUBLESHOOTING
DANGER ! Risk of injury due to electric shock.
Warning ! Before any trouble shooting, switch o the product.
Problems Probable causes Solutions
Qualifi cation
required
Product does
not blow
Blocked tube
Clear the blockage
No speci c
quali cation is
required
Blocked impeller
Battery is not secure
To secure the battery pack,
make sure the latches on the
top of the battery pack snap
into place
Battery is not charged
Charge the battery pack
according to the instructions
included with your model
To Next Page
