8.EXPLODED VIEW WITH PARTS LIST
Part no. Description Part no. Description Part no. Description
1 Bar Sleeve 33-4 Axle sleeve 49 Pressing plate
2 Bar 33-5 Output shaft gear 50 Screw
3 Chain 33-6 Bearing 51 Spring
4 Spanner 33-7 Screw 52 Push rod assy
5 Screw 34 Screw 52-1 Push rod
6 Axle sleeve 35 Protection dusty cover 52-2 Pulley
7 Brand label 36 Motor pump assy' 52-3 Pin
8 End cup 36-1 Screw 53 Pressing plate for push rod
9 Seal ring of end cup 36-2 Gear 54 Screw
10 E-ring 36-3 Gear sleeve 55 Brake pressing plate
11 Sprocket 36-4 Screw 56 Screw
12 Spring 36-5 Supporting plate 57 Control switch
13 Warning label 36-6 Wind deector 58 Pressing plate
14 Screw 36-7 Axle 59 Screw
15 Screw 36-8 Rotator 60 Front push rod assy
16 Right housing 36-9 Axle 60-1 Pin
17 Delivery connection seal ring 36-10 Screw 60-2 Rod
18 Screw 36-11 Spring washers 60-3 Front push rod
19 Screw 36-12 Gasket 61 Screw
20 Gasket 36-13 Gasket 62 Gasket
21 Nut 36-14 Hexagonal nut 63 Screw
22 Gasket 36-15 Stator 64 Fixing plate
23 Screw 36-16 Connection wire 65 Brake rod
24 Sponge 36-17 Motor back bracket 66 Spring
25 Pressing plate 36-18 Carbon brush holder 67 Gasket
26 Screw 36-19 Carbon brush 68 Screw
27 M8 bolt 36-20 Pressing plate of brush 69 Screw
28 Pressing plate 36-21 Screw 70 Screw
29 Screw 36-22 Screw 71 Base of delivery connection
assy
30 Oil tap assay' 36-23 Pump body 71-1 Base of delivery connection
30-1 Delivery connection oil tap 36-24 Turbine 71-2 O-rubber ring
30-2 Spong 36-25 Turbine gear 72 Output oil bracket
30-3 Delivery connection rubber sleeve 36-26 Pump spring 73 Screw
30-4 Delivery connection plug 37 Output oil tube 74 Gasket
30-5 Fuel tank 38 Cable wire 75 Protection bar
31 Oil tube 39 Cable sleeve 76 Spring
32 Oil cap assay' 40 Screw 77 Screw
32-1 Valve 41 Pressing 78 Left housing
32-2 Seal ring 42 Capacitor 79 Rating label
32-3 Oil cap 43 Pressing plate 80 Motor cover
32-4 Cover of oil cap 44 Screw 81 Screw
33 Output shaft assy 45 Switch button 82 Screw
33-1 Bearing 46 The self-locking button 83 Connection wire
33-2 Output shaft 47 The self-locking spring 84 Connection wire
33-3 Brake torsion spring 48 Switch 85 Connection wire
241
EN
