Parts list
Name
blade locking bolt
dish washer
460mm blade
blade support
blade support bushing
at key
blade support bushing
M6*8 hexagonal set screw
driving pulley
triangle belt
ST5*16 self-tapping screw
M6*16 tooth screw
pulley protective cover
M6 all-metal hexagon ange locking nut
wheel cover
M8 hexagon ange locking nut
bearing
wheel assembly
M6*12 tooth screw
shaft xed pressing plate
front axle assembly
front axle xed ring
ST4*12 self-tapping screw
at washer
head cover
M6 hexagon locking nut
11"dustproof wheel cover
ST4*16 self-tapping screw
wheel gear ring
wheel assembly
wheel cover-3
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
No.
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
Name
connecting rod
connecting rod tension spring
cable protecting sheath
deck assembly
height adjusting board
axle xed ring
opening washer
left output gear assembly
at washer
bearing
bearing bushing
cylindrical pin
gearbox assembly
right output gear assembly
M6*12 hexagon ange bolt
locating plate
M6*14 cross-recessed pan head screw
opening washer
rear axle assembly
adjusting washer
handle assembly
handle sheath
M8*16 hexagon ange bolt
right handle bracket
right torsional spring
long rod
left torsional spring
left handle bracket
M8*35mm hexagon bolt
square washer
engine rubber pad
Model:PLM1-46B140.4
9. EXPLODED VIEW WITH PARTS LIST 9. EXPLODED VIEW WITH PARTS LIST
