StetSom STX2448 - Overview; SEQUENCER and REM IN Connections; Power and Ground Connections; Display LCD and Encoder Control

18
1. SEQUENCER: 
AWG 18
2. REM IN: 
AWG 18
3. NEGATIVE POWER CONNECTOR (GND): 
AWG 13
4. POSITIVE POWER CONNECTOR (+BAT): 
AWG 13
1A
5. DISPLAY LCD: 
6. ENCODER: 

• ENTER funcon:
• RETURN funcon:
Overview
5
7
21 3 4
8
6
109
