Steve Silver DL250CBN - Assembly Instructions

DL250CBN
P
.2/7
Two people are recommended to the assembly
ASSEMBLY INSTRUCTIONS
STEP:1
STEP:2
STEP:3
STEP:4
A
Before you attach the legs, put the Mainframe (#A)
onto a raised platform such as a table or box. The
legs must not be touching the ground when they
are being attached.
NOTE: Only attach 3 Legs at this stage.
A
1
B
B
2
3
Attach three Legs (#B) to the Mainframe (#A) using
2 Bolt(#1) Lock Wsher(#2) and
Washer(#3)
per leg.
Note: Do not attach the 4th Leg at this stage.
Note: Do not tighten the screws at this step.
C
B
B
Remove the Mainframe (#A) from the raised platform
and place on the ground.
Attach the Bottom Panel (#C) to the 3 attached Legs
(#B).
A
1
B
2
3
Attach the 4th leg (#B) using
2 Bolt(#1) Lock Wsher(#2)
and
Washer(#3).
