1K resistor (1) #7357
Brown Black Black Brown Brown
Brown Black Black Orange Brown
100K resistor (1) #7365
Orange Orange Black Red Brown
33K resistor (1) #7409
Yellow Violet Black Brown Brown
4.7K resistor (1) #7359
Yellow Violet Black Black Brown
470Ω resistor (1) #7355
Next, we’re going to add some resisitors to our PCB. Like in the previous step, you’ll nd an
outline of each resistor and its value printed in their proper location on the PCB. Resistors
are not polarized, so it doesn’t matter which lead goes in which hole. Match resistors to the
values on the PCB, a few at a time, and solder in place. Clip the leads close to the board, but
not touching the board so you don’t damage the solder pads.
INSTALL 5
RESISTORS
