INSTALL LED
INDICATOR
LIGHT
1212
Like some of the caps and diodes, the LED is polarized and
has to be installed in a specic direction. The negative
lead of the diode has a at edge and is shorter than the positive.
5mm LED mounting bezel (1) #7432
5mm white LED (1) #7422
case
++
The LED mounting bezel consists of two main parts: A
ring that the LED ts into, and a plastic plug that goes
over the LED from the back side to keep it in place.
Install the mounting bezel through the front of the
enclosure. From the inside, slip a lock washer and nut
on and tighten it up using a 3/8" wrench. Insert the LED
into the bezel so that the two leads are parallel with the
top and bottom of the housing and the shorter lead is
closest to the outside of the enclosure. Feed the leads
through the plastic plug, press the plug down until it’s
tight in the bezel. The LED will be held in place when
you solder the leads to the switches and circuit board.
For a more secure mount, you can run a bead of clear
silicone adhesive around the plastic plug.
