STI 6400 - Page 2

VIEW OF CIRCUIT BOARD
JP5
JP2
JP4
JP3
JP7
ALARM
DURATION
SWITCH
ALARM VOLUME SWITCH
ARMING SWITCH
(ON)
(ON)
(OFF)
(OFF)
(OFF)
IMMEDIATE ARMING ACTIVATION
High Volume* (105 dB)
Low Volume (95 dB)
Immediate Arming* ON*
15 Second Arming Delay OFF
Immediate Arming Activation*
OFF*
15 Second Activation Delay ON
30 Second Alarm Duration* OFF*
180 Second Alarm Duration OFF
Continuous Alarm Duration ON
Door Prop Mode (5 Beeps)
JP2 JP3 JP4 JP5 JP7
*Factory Settings
NOTE: Slide black lever to desired ON/OFF position as labelled on circuit board
FEATURE
ON*
OFF
OFF*
ON
OFF
ON ON
TERMINAL BLOCK
NC
CO M
NO
GD
V+
RS1
RS2
KEYS W
TERMINAL BLOCK WIRING CONNECTIONS
FORM C
DR Y
CONTACTS
REMOTE POWER
INPUT
9-24 VDC
REED SWITCH TERMINAL S
KEY SWITCH TERMINAL S
FIGURE 4
(FACTORY DEFAULT SETTINGS)
CIRCUIT BOARD SET-UP MOUNTING OPTIONS
FIGURE 7
TYPICAL DOUBLE DOOR INSTALLATION
STI-6402
FIGURE 6
FIGURE 5
DOOR
DOOR STOP
JAM
MAGNET
6400 UNIT
MAGNET MUST BE
INSTALLED OPPOSITE
RAISED RIB ON OUTER COVER.
SPACERS (USE
AS NECESSARY)
RAWL PLUG
(2) PROVIDED
TYPICAL FLUSH MOUNT DOOR JAM
INSTALLATION
DOOR
SWING
NOTE: 2 SPACERS MUST BE
USED ON STEEL DOORS
SCREW
6 x 1 1/4 in.
(2) PROVIDED
MAGNET
6400 UNIT
DOOR STOP
SWING
DOOR
TYPICAL RECESSED MOUNT DOOR JAM
INSTALLATION
MAGNET ASM.
19 mm [3/4 in.]
MAXIMUM GAP
(SEE FASTING
ATTACHMENTS
ABOVE )
ID6400-6400WIR · Revised 01/17 -001 · Printed in England
