Edition Manual Chapter Page
2014-09-09 Workshop Manual, GGP Park 6 Control wires 12
3. When the parking brake is activated the
distance between the brake arm’s rear
stop and the brake arm should be 7-8 mm.
In the illustration the brake arm’s return
spring has been dismantled to make the
picture more explicit.
4. If the distance is not correct it is adjusted
by turning the nut on the brake calliper.
Release the parking brake and turn
towards + to increase the distance, and
towards – to reduce the distance.
Follow-up work
Test driving.
