Key# Part # Description Qty.
Replacement Parts List for Model Number T8730
2L-5027-02
Key# Part # Description Qty.
29
30
38
34
34
37
34
33
38
40
37
30
29
33
1
4
3
2
21
19
20
18
18
20
6
35
22
26
25
24
16
17
7
13
28
13
16
17
36
27
39
12
28
43
32
31
9
15
14
10
8
17
16
17
16
4A-6407-00
2S-9108-02
2S-9109-02
2S-9107-01
1B-4082-99
3M-6273-00
4A-7609-01
8S-6841-02
2Q-4017-00
2Q-4018-00
2B-4043-00
3M-6884-00
1B-6195-00
3M-6274-00
2W-6258-03
8S-6842-02
8S-6850-05
4A-5423-02
1A-7022-01
2S-4597-01
8S-6851-01
2S-6387-01
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
3/4" BLUE TOP ONLY
SIDE RAIL - RIGHT HAND
SIDE RAIL - LEFT HAND
END RAIL
#8 X 9/16 SHEET METAL SCREW
U-SUPPORT CLIP (PLASTIC)
CASTER BEAM ASSEMBLY
CASTER BEAM ONLY
3" CASTER - NON LOCKING
3" CASTER - WITH LOCK
3/8" PUSH NUT
STOP SPOOL
3/8-16 X 2 3/4 HEX HEAD BOLT
TUBE PLUG - 1" X 2"
BOTTOM BOARD
LINKAGE
STRUT TUBE
HINGE & MOUNTING BRACKET ASSEMBLY
LEG ASSEMBLY - BLUE
MOUNTING BRACKET ONLY
U SUPPORT
1" U-CLIP
2
2
2
2
124
8
2
2
2
2
4
8
8
4
1
4
4
4
2
8
2
6
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
3B-6007-00
2B-4035-00
3M-6248-00
1B-6495-00
2B-4053-00
1B-4135-00
1B-4097-01
1B-6459-00
1N-0001-00
1B-4082-99
2B-4047-98
1B-4089-00
7B-4061-00
7B-6161-00
2B-6087-00
2B-4054-00
3M-6715-00
5A-6700-02
2L-5027-02
2S-6875-02
Not Used
RIVET - 1/4 X 2 3/8"
1/4" PUSH NUT
2" SQUARE PLUG
3/8-16 x 3 1/2 HEX HEAD BOLT
3/8-16 NYLOC JAM NUT
1/4-20 x 2 3/4 HEX HEAD BOLT
1/4-20 x 1 1/2 PHILLIPS HEAD SCREW
1/4-20 X 3 1/2 CARRIAGE BOLT
1/4-20 WING NUT
#8 X 9/16 SHEET METAL SCREW
1/4-20 NYLOC JAM NUT
#8-32 x 1 1/4 SHEET METAL SCREW
3/4 OD X 13/32 ID X 3/4 LONG SPACER
1/2 OD X 9/32 ID X 3/8 LONG SPACER
1/4" PLASTIC WASHER
3/8" PLASTIC WASHER
CORNER PROTECTOR
66" NET & POST SET (NOT SHOWN)
OWNERS MANUAL - T8730
SUPPORT PLATE
4
4
4
4
12
4
4
4
4
4
12
4
4
4
4
8
4
1
1
4
