18
English
BR 500, BR 550, BR 600
It may be necessary to correct the
adjustment of the throttle cable after
assembling the blower or after a
prolonged period of operation.
Adjust the throttle cable only when
the machine is completely and
properly assembled.
: Move the throttle trigger to the full
throttle position – as far as stop.
: Turn the screw in the throttle trigger
slowly clockwise until you feel initial
resistance.
: Adjust the harness straps so that
the backplate is held firmly and
comfortably against your back.
A = Adjust height
B = Adjust angle
Tightening the harness straps
: Pull the ends of the straps
downward.
Loosening the harness straps
: Lift the tabs of the two sliding
adjusters.
Adjusting the Throttle Cable Fitting the Harness
373BA003 KN
373BA004 KN
