BT 130
English
26
Ignition System
Electronic (breakerless) magneto
ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Drilling gear
Two-stage spur gear drive
Weight
Dimensions
Contact your STIHL dealer for
information regarding special
accessories that may be available for
your product.
Displacement: 36.3 cc
(2.22 cu.in)
Bore: 43 mm (1.693 in)
Stroke: 25 mm (0.984 in)
Engine power to
ISO 7293:
1.4 kW
(1.88 bhp) at
8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed: 9,500 rpm
Spark plug (resistor
type): NGK CMR 6H
Electrode gap: 0.5 mm
(0.020 in)
Fuel tank capacity: 0.53 l (17.9 fl.oz)
Gear ratio: 47.5:1
Max. spindle speed: 200 rpm
Max. torque at drilling
spindle:
81 Nm
(59.74 lbf. ft)
Lubrication: STIHL gear
lubricant for
brushcutters
Dry, without drilling tool
(auger):
21.8 lbs
(9.9 kg)
Length with handle
frame:
400 mm
(15.748 in)
Width with handle frame: 530 mm
(20.866 in)
Height without drilling
tool (auger):
365 mm
(14.370 in)
Special Accessories
