Stihl BT 45 User Manual

BT 45
English
12
Assist handle for planting auger
N Loosen the two wing screws (3) on
the flange (4).
N Make sure the polymer bushing is
properly seated (see arrow).
N Push the flange onto the machine
as far as stop and line it up.
N Insert the handle tube (5) in the
flange.
N Move the handle to the required
position and tighten down the two
wing screws firmly.
Your power drill can be used for a range
of applications, e.g. fence-building and
carpentry (kit for wood drill) and in
landscaping and gardening (kit for
planting hole auger).
General
To change the drilling tool, always shut
off the engine and set the rotary knob
to N.
Always fit the assist handle specified for
the drilling tool you intend to use. See
"Mounting the Handles".
During operation, always hold the
machine firmly with both hands to
control unexpected reactive forces
caused by the drilling tool jamming in or
passing through the material.
Working with the planting hole auger
N Make sure you have a safe and
secure footing.
During operation, always hold the
machine firmly with both hands to
control unexpected reactive forces that
may occur if the drilling tool jams, e.g. in
rocky ground. Release the throttle
trigger if the drilling tool jams.
The planting hole auger should be
operated only with the gearbox set to
position 1. The tool speed is too high for
drilling planting holes when the gearbox
is set to poistion 2.
421BA037 KN
3
4
3
5
421BA007 KN
Using the Unit
421BA002 KN

Stihl BT 45 Specifications

General

Engine Type	2-stroke
Displacement	27.2 cc
Power Output	0.9 kW (1.2 hp)
Weight	5.2 kg
Power Source	Gasoline
No-Load Speed	0 - 300 rpm
