STIHL also stands for premium service quality.
Our dealers guarantee competent advice and
instruction as well as comprehensive service
support.
STIHL expressly commit themselves to a sus‐
tainable and responsible handling of natural
resources. This user manual is intended to help
you use your STIHL product safely and in an
environmentally friendly manner over a long
service life.
We thank you for your confidence in us and hope
you will enjoy working with your STIHL product.
Dr. Nikolas Stihl
IMPORTANT! READ BEFORE USING AND
KEEP IN A SAFE PLACE FOR REFERENCE.
2 Guide to Using this Manual
2.1 Applicable Documents
► In addition to this instruction manual, read,
understand and keep the following documents:
–
Instruction manual for the STIHL machine
Local safety regulations apply.
2.2 Warning Notices in Text
DANGER
■ This notice refers to risks which result in seri‐
ous or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
WARNING
■ This notice refers to risks which can result in
serious or fatal injury.
► Serious or fatal injuries can be avoided by
taking the precautions mentioned.
NOTICE
■ This notice refers to risks which can result in
damage to property.
► Damage to property can be avoided by tak‐
ing the precautions mentioned.
2.3 Symbols in the Text
This symbol indicates a chapter in this
instruction manual.
3 Overview
3.1 Engine
1 Starter handle
The starter handle is used to start the engine.
2 Fuel tank
The fuel tank holds the fuel.
3 Fuel tank cap
The fuel tank cap seals the opening for add‐
ing petrol.
4 Air filter
The air filter filters the air taken in by the
engine.
5 Spark plug socket
The spark plug socket connects the ignition
lead to the spark plug.
6 Oil dipstick
The oil dipstick measures the engine oil level.
3.2 Symbols
The symbols can be on the engine and have the
following meaning:
Read, understand and keep the
instruction manual.
English 2 Guide to Using this Manual
8 0478-983-9945-A
