FS 310
English
27
N Turn the cap counterclockwise
(approx. 1/4 turn).
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling,
and do not overfill the tank.
Closing the toolless filler cap
N Position the cap with the grip in an
upright position; the raised
positioning marks must line up.
N Turn cap clockwise as far as it will
go (approx. 1/4 turn).
N Fold the grip down so that it is flush
with the surface.
If the grip is not flush with the surface
and the lug on the clip does not engage
entirely in the recess (arrow), the cap is
not properly closed and the steps
described above must be repeated. See
also the "Toolless cap with grip" section
in the Safety Precautions.
Opening the threaded filler cap
N Turn the cap counterclockwise until
it can be removed from the tank
opening.
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank.
Closing the threaded filler cap
N Position cap.
N Turn the cap clockwise as far as it
will go and tighten it as securely as
possible by hand.
249BA054 KN
249BA055 KN
249BA056 KN
002BA447 KN
002BA448 KN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl FS 310 and is the answer not in the manual?

Stihl FS 310 Specifications

General IconGeneral
Power Output1.4 kW
Engine Type2-stroke
Shaft TypeStraight
Sound Power Level112 dB(A)
Engine Displacement36.3 cc
Fuel Capacity0.95 liters
Cutting Diameter23-25 cm
Cutting Width23-25 cm
StarterRecoil
