FS 310
English
35
WARNING
To reduce the risk of fire and burn injury,
use only spark plugs authorized by
STIHL. Always press spark plug boot (1)
snugly onto spark plug terminal (2) of the
proper size. (Note: If terminal has
detachable SAE adapter nut, it must be
attached.) A loose connection between
spark plug boot and ignition wire
connector in the boot may create arcing
that could ignite combustible fumes and
cause a fire.
Installing the spark plug
N Screw home the spark plug, fit the
boot and press it down firmly.
Use STIHL gear lubricant (special
accessory) for lubrication.
N Check grease level about every 100
hours of operation.
N Unscrew the filler plug (1). If no
grease can be seen on the inside of
the filler plug, screw the tube of
lubricant (2) into the filler hole.
N Squeeze up to 1/5 oz (5 g) grease
into the gearbox.
NOTICE
Do not completely fill the gearbox with
grease.
N Refit the filler plug and tighten it
down firmly.
Replacing the Starter Rope
N Push the slide control in direction of
arrow h – to STOP-0.
N Take out the screws (1).
N Remove the starter cover (2) from
the housing.
