FS 110, FS 110 R
English
47
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Overall length
Features
Contact your STIHL dealer for
information regarding special
accessories that may be available for
your product.
Displacement: 31.4 cc (1.92 cu.in)
Bore: 40 mm (1.57 in)
Stroke: 25 mm (0.98 in)
Engine power to
ISO 8893:
1.05 kW (1.4 bhp)
at 7,000 rpm
Idle speed: 2,800 rpm
Cut-off speed
(rated): 10,200 rpm
Max. output shaft
speed (cutting
attachment): 7,500 rpm
Valve clearance:
Inlet valve: 0.10 mm (0.004 in)
Exhaust valve: 0.10 mm (0.004 in)
Spark plug (resistor
type): Bosch USR 7 AC
Electrode gap: 0.5 mm (0.02 in)
Fuel tank capacity: 0.53 l (17.9 fl.oz)
Dry, without cutting attachment and
deflector
FS 110: 5.8 kg (12.8 lbs)
FS 110 R: 5.5 kg (12.1 lbs)
without cutting
attachment 1800 mm (71 in)
R Loop handle
Z Spark arresting screen in muffler
Special Accessories
