HLA 65
English
27
Definitions
1. Battery Compartment
Accommodates the battery in the
unit.
2. Control Handle
The handle of the trimmer held by
the rear hand.
3. Trigger Switch Lockout
Must be depressed before the
trigger switch can be activated.
4. Trigger Switch
Switches the motor on and off and
controls the speed of the motor.
5. Retaining Latch
Locks or unlocks the trigger switch.
6. Loop Handle
For easy control of machine during
cutting work.
7. Carrying Ring
Connects the unit to the harness.
8. Drive Tube with Handle Hose
Encloses and protects the cables
between the motor and control
handle. For holding and controlling
the unit with the hand during
operation.
9. Blade Scabbard
Covers cutting blades when hedge
trimmer is not in use.
10. Cutting Blades
Steel blades for cutting hedges and
shrubs.
11. Adjusting Grip
Used to set cutter bar to the
required angle.
12. Blade Drive Gear
Converts rotary movement of motor
into reciprocating movement of
cutting blades.
13. Cutter Bar Adjusting Mechanism
For adjusting the angle of the cutter
bar and cutting blades.
14. Sliding Sleeve
Locks and unlocks the cutter bar
adjusting mechanism.
15. Battery Locking Tabs
Secure the battery in the unit.
16. Battery
Supplies the motor with electrical
power.
17. Light Emitting Diodes (LED) on
Battery
Indicate the state of charge and
operating condition of the battery.
18. Push Button
For activating light emitting diodes
(LED) on battery.
19. Charger
Charges the battery.
20. Light Emitting Diode (LED) on
Charger
Indicates charger operating mode
and certain problems.
21. Power Supply Cord
Supplies electric current to charger.
Battery
The unit can be operated only with
original STIHL rechargeable batteries.
Running time is dependent on the
energy content of the battery.
Charger
Specifications
Model: Lithium-ion
AL 100
Mains voltage: 120 V
Rated current: 1.3 A
Frequency: 60 Hz
Power consumption: 75 W
Charging current: 1.6 A
Protection class: II, E (double
insulated)
AL 300
Mains voltage: 120 V
Rated current: 4.7 A
Frequency: 60 Hz
Power consumption: 330 W
Charging current: 6.5 A
Protection class: II, E (double
insulated)
