Stihl KM 55 R User Manual

KM 55 R, KM 55 RC
English
19
N Too much oil in fuel mix.
N Dirty air filter.
N Unfavorable running conditions,
e.g. operating at part load.
Fit a new spark plug after approx. 100
operating hours or earlier if the
electrodes are badly eroded.
Installing the spark plug
N Screw home the spark plug, fit the
boot and press it down firmly.
If engine running behavior is
unsatisfactory even though the air filter
is clean and the carburetor is properly
adjusted, the cause may be the muffler.
Have the muffler checked for
contamination (carbonization) by your
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer.
Warning!
To reduce the risk of fire and burn injury,
use only spark plugs authorized by
STIHL. Always press spark plug boot (2)
snugly onto spark plug terminal (1) of
the proper size. (Note: If terminal has
detachable SAE adapter nut, it must be
attached.) A loose connection between
spark plug boot and ignition wire con-
nector in the boot may create arcing that
could ignite combustible fumes and
cause a fire.
000BA036 TR
1
Engine Running Behavior

Stihl KM 55 R Specifications

General

Engine Type	2-stroke
Displacement	27.2 cc
Weight	4.4 kg
Weight (lbs)	9.7 lbs
Engine Power	0.8 kW / 1.1 hp
