Stihl KM 90 R User Manual

KM 90 R
English
28
1 Fuel Filler Cap
2 Carburetor Adjusting Screws
3 Fuel Pump
4 Starter Grip
5 Muffler with Spark Arresting Screen
6 Coupling Sleeve
7 Wing Screw
8 Loop Handle
9 Barrier Bar
10 Carrying Ring
11 Slide Control
12 Throttle Trigger Lockout
13 Throttle Trigger
14 Spark Plug Boot
15 Choke Knob
16 Air Filter Cover
17 Fuel Tank
18 Machine Support
# Serial Number
Main Parts
11
16
13
9
7
14
1
3
4
17
18
8
10
463BA004 KN
#
2
5
6
12
15

Stihl KM 90 R Specifications

General

Engine Type	2-stroke
Displacement	28.4 cc
Sound Pressure Level	96 dB(A)
Sound Power Level	107 dB(A)
Powerhead Weight	4.4 kg
Weight	4.4 kg (9.7 lbs)
Engine Power	0.8 kW
Fuel Tank Volume	0.44 l
Recommended Oil Mix	50:1 with STIHL HP Ultra oil
