Stihl KM 94 R User Manual

KM 94 R
English
18
N Unplug spark plug boot (3)
N Unscrew spark plug
Checking the Spark Plug
N Clean dirty spark plug.
N Check electrode gap (A) and
readjust if necessary – see chapter
"Specifications."
N Use only resistor type spark plugs of
the approved range.
Rectify problems which have caused
fouling of spark plug:
– too much oil in fuel mix,
– dirty air filter,
– unfavorable running conditions, e.g.
operating at part load.
WARNING
To reduce the risk of fire and burn injury,
use only spark plugs authorized by
STIHL. Always press spark plug boot (1)
snugly onto spark plug terminal (2) of the
proper size. (Note: If terminal has
detachable SAE adapter nut, it must be
securely attached.) A loose connection
between spark plug boot and ignition
wire connector in the boot may create
arcing that could ignite combustible
fumes and cause a fire.
Installing the Spark Plug
N Fit the spark plug and tighten it
down firmly.
N Press the boot firmly onto the spark
plug.
N Fit the cap (1), insert the screw (2)
and tighten it down firmly.
3
0208BA038 KN
000BA039 KN
A
2
1
002BA363 KN
1
2
0208BA039 KN

Stihl KM 94 R Specifications

General

Displacement	27.2 cm³
Power Output	0.9 kW
Weight	4.0 kg
Engine Type	2-stroke
Fuel Tank Capacity	0.35 l
Engine Power	0.9 kW
Powerhead Weight	4.0 kg
Fuel Capacity	0.54 l
